Titan 12V Electric Rewind Hose Reel – 500′ #T4322E

Titan 12V Electric Rewind Hose Reel – 500′ #T4322E

• Heavy Duty Aluminum Frame
• Super swivel with ball bearing support and grease fitting
• Carbon steel manifold
• Adjustable molded resin drag
• Aluminum Disks, PVC spool, Plated Steel Hardware
• 3/8″ID – 3/4″OD

Full Frame	Electric Rewind	Spool Width   (in.)	Spool Diameter (in.)
4306H		6	6
4312H	4312E	12	6
4318H	4318E	18	6
4322H	4322E	22	6
4328H	4328E	28	6
4012-6	4012-6E	12	6
4018-6	4018-6E	18	6
4022-6	4022-6E	22	6
4028-6	4028-6E	28	6
4012-8	4012-8E	12	8
4018-8	4018-8E	18	8
4022-8	4022-8E	22	8
4028-8	4028-8E	28	8

*PICTURED HOSE GUIDE IS NOT INCLUDED

*SHIPS TRUCK FREIGHT NOT INCLUDED

See all other pressure washer hose reels.

TITAN Hose Reels

Specifications

Max Pressure	5000 PSI
Max Temp.	140°F
Max Hose Cap.	500′
Weight	50 lbs
