Summit Hose Reel – 550′ #SM22

Summit Hose Reel – 550′ #SM22

Summit Hose Reels are top of the line, professional hose reels. All reels are pressure tested and built from the finest, high-quality materials ensuring long-lasting reel life. Swivels are brass with Viton seals and discs are constructed of 16 gauge galvanized steel with rolled edges and reinforcement ridge.

• Square frame design generally found only on large heavy duty reels.
• Disc is made of 16 gauge galvanized steel with rolled end & strengthening ridge.
• Bolt on spring-loaded locks allow for easy field adjustment or replacement. Comes standard on all reels.
• High quality sealed bearings. No lubrication required.
• Adjustable tension that keeps hose from free rolling.
• Pre-drilled mounting holes for easy installation on a truck, trailer or wall mounting.
• Viton seals are standard on all 1/2″ reel models.
• All reels are rated at 250 degrees and 3500 PSI operating pressure.
• All reels are pressure tested.
• State of the art powder coated paint system. Builds four times the film thickness and is 10 times more resistant to scratching and chipping.
• Powder coated reels provide twice the resistance to rust as does liquid coating.
• All reels are built with the finest quality material available for long lasting service.

Steel crank handle has free turning plastic grip. The frame has predrilled mounting holes and a lifetime warranty. Powder-coated models are highly resistant to rust and chipping.

• 550′ of 3/8″
• 4000psi
• 250 degrees
• 1/2″ FPT inlet/outlet

See all other pressure washer hose reels.

Be sure to check out the rest of our Summit Hose Reels. For more information on this product, contact Power Wash Store today!

Reel Dimension in Inches:

A	B	C	D	E	F	Unit Weight
27″	22″	6″	17″	34″	18″	31 pounds

Hose Capacity in Feet:

1/4″ ID	3/8″ ID	1/2″ ID	5/8″ ID	1′ ID
700′	500′	350′	200′	150′
