Summit Hose Reel – 450′ #SM18

Summit Hose Reel – 450′ #SM18

Summit Hose Reels are top of the line, professional hose reels. All reels are pressure tested and built from the finest, high-quality materials ensuring long-lasting reel life. Swivels are brass with Viton seals and discs are constructed of 16 gauge galvanized steel with rolled edges and reinforcement ridge.

• Square frame design generally found only on large heavy duty reels.
• Disc is made of 16 gauge galvanized steel with rolled end & strengthening ridge.
• Bolt on spring-loaded locks allow for easy field adjustment or replacement. Comes standard on all reels.
• High quality sealed bearings. No lubrication required.
• Adjustable tension that keeps hose from free rolling.
• Pre-drilled mounting holes for easy installation on a truck, trailer or wall mounting.
• Viton seals are standard on all 1/2″ reel models.
• All reels are rated at 250 degrees and 3500 PSI operating pressure.
• All reels are pressure tested.
• State of the art powder coated paint system. Builds four times the film thickness and is 10 times more resistant to scratching and chipping.
• Powder coated reels provide twice the resistance to rust as does liquid coating.
• All reels are built with the finest quality material available for long lasting serivice.

The steel crank handle has a free turning plastic grip. The frame has predrilled mounting holes and a lifetime warranty. Powder-coated models are highly resistant to rust and chipping.

• 450′ of 3/8″
• 4000psi
• 250 degrees
• 1/2″ FPT inlet/outlet

See all other pressure washer hose reels.

Reel Dimension in Inches:

A	B	C	D	E	F	Unit Weight
23″	18″	6″	17″	30″	18″	27 pounds

Hose Capacity in Feet:

1/4″ ID	3/8″ ID	1/2″ ID	5/8″ ID	1′ ID
600′	400′	300′	150′	125′
